$489.00
| Item | Specification |
|---|---|
| Maximum operating voltage (Un) | 1000 V DC |
| Rated insulation voltage (Ui) | 1000 V |
| Rated impulse voltage (Uimp) | 6 kV |
| Maximum input current per battery tower | 30A |
| Maximum output current | 50A |
| Rated short-time withstand current (Icw) | <4.5 kA |
| Pollution degree | 3 |
| Enclosure | Aluminium alloy |
| Degree of protection | IP65 |
| Operating temperature range | -40℃ ~ +50 ℃ |
| Storage temperature range | -40℃ ~ +50 ℃ |
| Humidity | 5 % to 95 %, non-condensing |
| Altitude | ≤ 4,000 m |
| Length | Width | Height | |
| Unpacked Dimension | 390mm | 300mm | 140mm |
If installation services are required, our team can assist in arranging qualified installers for your project.
1.Actual working efficiency (including discharge power, energy loss, and standby consumption) may vary depending on battery voltage state, wiring layout, load power, ambient temperature, and long-term operating environment.
2.Installation must be carried out by certified electrical professionals in accordance with local electrical safety codes and manufacturer installation guidelines.
3.Product parameters, shell appearance and internal circuit layout may be subject to change without prior notice for technical iteration and performance upgrade.
4.Overload operation, unauthorized circuit modification, reverse wiring, or failure to follow operation manuals may lead to overheating, short-circuit damage or fire hazards. The manufacturer shall not be held liable for losses caused by such improper operations.
5.Stable and optimal working performance is guaranteed only within the rated voltage and temperature range marked on the product. Overvoltage, undervoltage or extreme high/low temperature environments will degrade service life and trigger protection shutdown.
6.This combiner box is exclusively designed for low-voltage lithium battery parallel connection. It is not applicable to lead-acid batteries, high-voltage battery packs or other incompatible energy storage equipment; damage arising from misapplication is not covered by warranty.
