$1,399.00
| Item | Specification |
|---|---|
| Max.PV array power | 15000 Wp STC |
| Max.input voltage | 1100 V |
| MPP voltage range/rated input voltage | 150V-1000V/630 V |
| Min.input voltage | 125V |
| Initial. feed in voltage | 180V |
| Max.operating input current | 32A/32A |
| Max.short circuit current | 48A/48A |
| Rated active power | 10000W |
| Rated apparent power | 10000 VA |
| Max.apparent power | 10000 VA |
| Max.input current from grid | 14.5A |
| Max.efficiency/European efficiency | 98.6%/98.2% |
| Operating temperature range | -25℃~60℃ |
| Self-consumption (at night) | <1W |
| Topology | Non-isolated |
| Degree of protection(as per IEC 60529) | IP66 |
| Length | Width | Height | |
| Unpacked Dimension | 503mm | 435mm | 183mm |
If installation services are required, our team can assist in arranging qualified installers for your project.
1.Actual inverter performance, including but not limited to conversion efficiency, output power, maximum PV input capacity and backup runtime, may vary depending on ambient temperature, solar irradiance, load conditions, wiring layout, battery matching status and local environmental factors.
2.Installation, wiring, commissioning and regular maintenance must be completed by certified electrical professionals, fully complying with local electrical codes, safety standards, grid connection regulations and official manufacturer operation guidelines.
3.All product specifications, exterior design, technical parameters and functional features are subject to revision without prior written notice for ongoing product optimization and technical upgrade.
4.Any damage, equipment malfunction, grid fault, fire risk or safety hazard caused by improper operation, unauthorized hardware/software modification, non-compliant installation, mismatched PV/battery accessories or violation of official safety instructions shall not be the liability of the manufacturer.
5.Stable output efficiency and long service life of the inverter can only be guaranteed when operated within the designated working, charging and storage temperature ranges. Extreme high/low temperatures, damp or dusty storage environment will degrade performance and shorten service lifespan.
6.Grid-tied inverter functions are subject to local power grid access policies; grid compatibility and feed-in power limits differ by region. The manufacturer does not guarantee unrestricted grid connection in all areas.
7.System energy yield calculation data shown on the display or monitoring platform is for reference only. Actual power generation will be affected by weather, shading, component aging and seasonal sunlight changes, which shall not constitute a product performance warranty basis.
8.The warranty coverage excludes failures induced by lightning strike, flood, thunderstorm, unstable grid voltage, man-made damage, long-term overload operation or use beyond the rated parameter limits.
Smarter, cleaner and more efficient systems for modern homes
